Product Summary

The MC74HC244ADW is a High–Performance Silicon–Gate CMOS.

Parametrics

MC74HC244ADW absolute maximum ratings : (1)DC Supply Voltage (Referenced to GND) : -0.5 to +7.0V; (2)DC Input Voltage (Referenced to GND) : -0.5 to VCC+0.5V; (3)DC Output Voltage (Referenced to GND) : -0.5 to VCC+0.5V; (4)DC Input Current, per Pin : ±20mA; (5)DC Output Current, per Pin : ±35mA; (6)DC Supply Current, VCC and GND Pins : ±75mA; (7)Power Dissipation in Still Air, Plastic : 750mW; (8)Storage Temperature : -65 to +150℃.

Features

MC74HC244ADW features: (1)Output Drive Capability: 15 LSTTL Loads; (2)Outputs Directly Interface to CMOS, NMOS, and TTL; (3)Operating Voltage Range: 2 to 6 V; (4)Low Input Current: 1 μA; (5)High Noise Immunity Characteristic of CMOS Devices; (6)In Compliance with the Requirements Defined by JEDEC Standard No. 7A; (7)Chip Complexity: 136 FETs or 34 Equivalent Gates.

Diagrams

MC74HC244ADW dimension
