Product Summary

The ADP3020A is a high-efficiency notebook computer power supply controller. It is optimized for converting the battery or adapter input into the system supply voltages required in notebook computers. The ADP3020A uses a dual-mode PWM/Power Saving Mode architecture to maintain efficiency over a wide load range. The oscillator frequency can be programmed for 200 kHz, 300 kHz, or 400 kHz operation, or it can be synchronized to an external clock signal of up to 600 kHz.

Parametrics

ADP3020A absolute maximum ratings: (1)VIN to AGND: -0.3 to 27V; (2)AGND to PGND: ±0.3V; (3)INTVCC: AGND-0.3 to 6V; (4)operating ambient temperature range: -40 to 85℃; (5)junction temperature range: -40 to 150℃; (6)lead temperature range: 300℃.

Features

ADP3020A features: (1)Wide Input Voltage Range: 4.5 V to 25 V; (2)High Conversion Efficiency > 96%; (3)Integrated Current Sense—No External Resistor Required; (4)Low Shutdown Current: 7 A (Typical); (5)Dual Synchronous Buck Controllers with Selectable; (6)Programmable PWM Frequency; (7)Integrated Linear Regulator Controller; (8)Extensive Circuit Protection Functions; (9)38-Lead TSSOP Package.

Diagrams

ADP3020A block diagram
