Product Summary
The MIT-SH-112LM is a 10A Miniature Power PC Board Relay.
Parametrics
MIT-SH-112LM absolute maximum ratings: (1)Ratings: 10A @ 240VAC resistive, TV-5 @ 120VAC tungsten 25,000ops; (2)Max. Switched Voltage: AC: 240V; (3)DC: 30V; (4)Max. Switched Current: 10A; (5)Max. Switched Power: 2,400VA, 300W.
Features
MIT-SH-112LM features: (1)Meet UL 508, VDE0435, SEMKO and SEV requirements; (2)1 Form A contact arrangements; (3)UL TV-5 rating available; (4)Immersion cleanable, sealed version available; (5)Meet 5,000V dielectric voltage between coil and contacts; (6)Meet 10,000V surge voltage between coil and contacts (1.2 / 50μs).
Diagrams
 |
