Product Summary

The S5A3159DCKR is a single-pole double throw (SPDT) analog switch that is designed to operate from 1.65-V to 5.5-V. The device offers a low ON-state resistance and an excellent ON-resistance, matching with the break-before-make feature to prevent signal distortion during the transferring of a signal from one channel to another. The S5A3159DCKR has an excellent total harmonic distortion (THD) performance and consumes very low power. These features make this device suitable for portable audio applications. The applications of the S5A3159DCKR are Cell Phones, PDAs, Portable Instrumentation.

Parametrics

S5A3159DCKR absolute maximum ratings: (1)Supply voltage range: -0.5 to 6.5V; (2)Analog voltage range: -0.5 to V+ + 0.5V; (3)Analog port diode current: ±50mA; (4)ON-state switch current: ±200mA; (5)ON-state peak switch current: ±400mA; (6)Digital input voltage range: -0.5 to 6.5V; (7)Digital input clamp current: -50mA; (8)Continuous current through V+ or GND: ±100mA; (9)Package thermal impedance: 165℃; (10)Storage temperature range: -65℃ to 150℃.

Features

S5A3159DCKR features: (1)Specified Break-Before-Make Switching; (2)Low ON-State Resistance (1Ω); (3)Control Inputs Are 5-V Tolerant; (4)Low Charge Injection; (5)Excellent ON-Resistance Matching; (6)Low Total Harmonic Distortion; (7)1.65-V to 5.5-V Single-Supply Operation; (8)Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II; (9)ESD Performance Tested Per JESD 22: 2000-V Human-Body Mode(A114-B, Class II), 1000-V Charged-Device Model (C101).

Diagrams

S5A3159DCKR diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TS5A3159DCKR
TS5A3159DCKR
Texas Instruments
Analog Switch ICs 1-Ohm SPDT Analog Switch
Data Sheet
0-1: $0.50
1-25: $0.40
25-100: $0.35
100-250: $0.32
TS5A3159DCKRE4
TS5A3159DCKRE4
Texas Instruments
Analog Switch ICs 1-Ohm SPDT Analog Switch
Data Sheet
0-1: $0.58
1-25: $0.45
25-100: $0.36
100-250: $0.30
TS5A3159DCKRG4
TS5A3159DCKRG4
Texas Instruments
Analog Switch ICs 1O SPDT Ana Sw
Data Sheet
0-2400: $0.19
2400-3000: $0.19
3000-12000: $0.19
