Product Summary
The TLP759 is a TOSHIBA photocoupler. It consists of a high-output light emitting diode and a high speed detector of one chip photo diode-transistor. It has no internal base connection, and a faraday shield integrated on the photodetector chip provides an effective common mode noise transient immunity.
Parametrics
TLP759 absolute maximum ratings: (1)forward current: 25mA; (2)pulse forward current: 50mA; (3)reverse voltage: 5V; (4)diode power dissipation: 45mW; (5)output current: 8mA; (6)peak output current: 16mA; (7)output power dissipation: 100mW.
Features
TLP759 features: (1)isolation voltage: 5000V; (2)switching speed: tpHL=0.2μs; (3)TTL compatible; (4)UL recognized; (5)option type; (5)maximum operating insulation voltage.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLP759 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
TLP759IGM |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
TLP759F |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
TLP759(IGM) |
Other |
|
Data Sheet |
Negotiable |
|
||||
