Product Summary

The NJM3414AM(TE3) is a high gain, high output current, high output voltage swing dual operational amplifier capable of driving 70mA.

Parametrics

NJM3414AM(TE3) absolute maximum ratings: (1)supply voltage V+(V+/V-): 15V or ±7.5V; (2)differential input voltage (VID): 15V; (3)input voltage (VIC): -0.3V to +15V; (4)operating temperature range Topr: -20℃ to +75℃; (5)storage temperature range Tstg: -40℃ to +125℃.

Features

NJM3414AM(TE3) features: (1)single supply; (2)operating voltage: +3V to +15V; (3)high output current: 70mA; (4)slew rate: 1.0V/us typ.; (5)package outline: DIP8, DMP8, SIP8, SSOP8; (6)bipolar technology.

Diagrams

NJM3414AM(TE3) diagram
