Product Summary
The LR1120 battery is an Alkaline Button Cell Battery.
Parametrics
LR1120 absolute maximum ratings: (1)Nominal Voltage 1,5 V; (2)Capacity 73 mAh, Discharge over 5,62 kΩ at 20℃ to 0,9 V; (3)Internal Resistance Below 20 Ω at 20℃; (4)Operating Temperature 0℃ – 60℃.
Features
LR1120 features: (1)Chemical system Zinc / Manganese Dioxide, high drain; (2)Nominal Voltage 1,5 V; (3)Capacity 73 mAh, Discharge over 5,62 kΩ at 20℃ to 0,9 V; (4)Internal Resistance Below 20 Ω at 20℃; (5)Operating Temperature 0℃ – 60℃; (6)Self Discharge Less than 10% per year at 20℃; (7)Weight ~1,36 g.
Diagrams
 |
