Product Summary
The MAX4614EUD is a low-voltage, high-speed, quad, SPST CMOS analog switch. It is pin compatible with the industry-standard 74HC4066/MAX4610 analog switches. On-resistance is matched between switches to 1max and is flat over the specified signal range. Each switch handles V+ to GND analog signal levels. Maximum off-leakage current is only 1nA at TA = +25°C and 6nA at TA = +85°C. Its applications include Battery-Operated Equipment, Audio/Video Signal Routing, Low-Voltage Data-Acquisition Systems, Sample-and-Hold Circuits, Communication Circuits.
Parametrics
MAX4614EUD absolute maximum ratings: (1)voltage referenced to GND: -0.3 to 6V; (2)continuous current: 75mA; (3)peak current: 200mA; (4)continuous power dissipation: 500mW; (5)operating temperature ranges: 0 to 70°C; (6)lead temperature: 300°C.
Features
MAX4614EUD features: (1)Fast Switching Times; (2)Pin Compatible with Industry-Standard; (3)Guaranteed Match Between Channels; (4)Guaranteed Flatness Over Signal Range; (5)<6nA Off-Leakage Current Over Temperature; (6)Rail-to-Rail Signal Handling; (7)TTL/CMOS-Logic Compatible.
